lluminating: 45°/0°
Measuring Aperture: Φ8mm
Wavelength range: 400nm-700nm
Light source: LED
Integrating sphere size: Φ58mm
Sensor: Silicon photocell
Wavelength interval: 10nm
Measuring range of reflectivity: 0-200%
Display: 3.5 inch TFT capacitive touch color screen
Color space: CIELAB, XYZ, Yxy.LCH CIELUV
Color Difference Formula: △E*ab, △E*uv, △E*94, △E*cmc(2:1), △E*cmc(1:1), △E*cmc(ICE), CIE2000, △E*00, △E(h)
Observation of light source: A,C,D50,D55,D65,D75,F1,F2,F3,F4,F5,F6,F7,F8,F9,F10,F11,F12
Observation Angle: 2°/10°
Display content: Spectrogram/data, sample chromaticity value, color difference value/graph, qualified/unqualified result, color deviation
Measuring time: Approx. 1.5s
Repeatability: Spectral reflectivity: Within 0.1% of standard deviation; Within △E*ab0.04
Storage: 1000 pcs standard samples; 15000 pcs test samples
Battery Life: More than 3 millions of times in 5 years
Interface: USB to TTL Level
Operating Temperature Range: 0 – 40℃; 0-85%RH(No condensation); Elevation: below 2000 m
Storage Temperature: -20 – 50℃ 0-85%RH(No condensation)
Weight(Net): 600g
Dimensions: 90mmx77mmx230mm
