Maximum Operating Frequency: 67GHz
Length: 36 I
Impedance: 50 Ohms
Dielectric Constant (nominal): 1.4
Velocity of Propagation: 0.85
Temperature: -55 to 125°C
Nominal Outer Diameter: 0.120 inch (3mm)
Minimum Bend Radius (multiple bends): 0.5 inch (12.7mm)
Nominal Weight: 9g/ft (29.5 g/m)
Typical Insertion Loss at 67 GHz: -5.84 dB
Guaranteed Insertion Loss at 67 GHz: -6.77 dB
Guaranteed VSWR at 67 GHz: 1.45:1
Guaranteed Return Loss at 67 GHz: -14.73 dB
