Input power: AC 380V±10% 50HZ, Three-phase four-wire power supply
Leakage switch: 3P, 32A, Belt protection
Output power: 3500W
Motor Power: AC 120W/220V
Car speed: 0.33m/s(Second round), 0.1m/s (Three rounds of scratch)
Car trip: 1m
Test voltage: Single phase, AC 0~220V continuously adjustable, 50HZ
Three-phase, AC 0~380V continuously adjustable, 50HZ
Test current: 2~40A Adjustable
Testing frequency: 0 to 999999 times (can be preset)
Pulley diameter: Ordinary two-wheeled： Ф60, Ф80, Ф120, Ф160, Ф200
Weight: 0.5KG, 1KG, 2KG, 3KG, 7KG, 14KG, 21N, 28N
Failure judgment: 1. The test line is broken;
2. Test line short circuit;
3. The test line is shorted to ground.
Qualified judgment: When the line to be tested reaches the set number of tests, the machine stops working.
Volume: 2000mm×600mm×1650mm
Weight: About 500KG
