Measurement Range: 0-2000Gu
Application: Apply on paint, ink, stoving varnish, coating, wood products; Marble, granite, vitrified polished tile, pottery brick and porcelain; Plastic, paper; Other nonmetallic material.
Instrument Dimensions: 122x34x60mm
Projection Angle: 60°
Measuring Spot: （ellipse: long axis*minor axis）8mm*4mm
Output: connect the micro printer to realize real-time output of measured data
Division Value: 0.1Gu
Repeatability: 0.2Gu
Reproducibility: 0.4Gu
Indication Error: 1.0Gu
International Standard 60°: ISO－2813、ASTM－C584、ASTM－D523、DIN－67530、ASTM－D2457、JND-A60、JND-P60
National Standard 60°: GB 9754、GB 9966、GB 8807
Standard Accessories: Power adapter/user manual/warranty certification/standard board/software GlossW
Optional Accessories: micro-printer
Production Feature:
This gloss meter is designed and manufactured with the reference to the international standard ISO 2813 and China national standard GB/T9754;
Technical parameters are in accordance with ASTM D2457, ASTM D523 and GB/T13891, GB/T7706, GB/T8807 standard;
All performance indexes meet the primary working machine requirements of metrological verification procedures of national standard JJG696-2002 "mirror gloss meter and gloss board";
The delicate and light appearance is very convenient to carry and use.
Automatic calibration, no need to manual adjustment, high stability, namely the boot measurement.
All intelligent design, single bond operation, one hand can realize all operations.
Long life light source without replacement
LCD digital display, showing clear.
Built-in high capacity lithium battery can be recharged, full of electricity can measuring more than 12 hours continuously
Feature-rich, measuring accuracy, good repeatability, cost effectiveness.
