Rockwell Scales: HRA, HRB, HRC
Rockwell Testing Force: 60Kgf(588.4N)、100Kgf(980.7N)、150Kgf(1471N)
Brinell Scales: HBW1/30、HBW2.5/62.5、HBW10/100、HBW2.5/187.5
Brinell Testing Force: 31.25Kgf(306.5N)、62.5Kgf(612.9N、187.5Kgf(1839N)
Vickers Scales: HV 30、HV100
Vickers Testing Force: 30Kgf(294.2N)、100Kgf(980.7N)
Rockwell Hardness Indication: Analogue Display
Rockwell Resolution: 0.5HR
Loading Control: Electronic
Magnification of Microscope: Brinell:37.5x; Vickers:75x
Dwell Time: Adjustable 2~60s
Max. Height Of Specimen: Rockwell:170mm; Brinell, Vickers:140mm
Instrument Throat: 165mm
Dimension(LxWxH): 520 x215 x700mm
Packing Dimension: 650 x370 x960mm
Power supply: AC 220V/50Hz;AC110V/60Hz
Gross/Net Weight: 110Kg/90Kg
Execution Standard: ISO 6508，ASTM E18，JIS Z2245，GB/T230
Standard Delivery：
Instrument
Hardness Block（2033）HRC
Hardness Block（5770）HRC
Hardness Block（85100）HRB
Hardness Block HV30
Hardness Block HBW2.5/187.5
Slide Testboard
Set of Weights
Microscope
15X Electronic Measuring Eyepiece
2.5X Electronic Measuring Eyepiece
5X Vickers Objective
Warranty Card / Qualified Certificate
Ø1.588mm Ball Intender
Vickers Intender
Φ2.5mm Brinell Intender
Φ5mm Brinell Intender
Cone Diamond Intender
Ø150mm Flat Anvil
Ø60mm Flat Anvil
Ø40mm Vshape Anvil
Power Cord
Bubble Level Meter
Toolbox
Dust Cover
Operation Manual / Packing List
Optional Accessories：
1/8” Ball Intender
Ø1/8” Steel Ball
1/4” Ball Intender
Ø 1/4” Steel Ball
1/2” Ball Intender
Ø 1/2” Steel Ball
