Application: Metallurgy ,metrology , Building materials, research institutes ,hardening shops, stainless steel, automotive, railway, energy, steel, aviation , roller plants, tube rolling mills, foundries,
Turret Type: Motorized Auto Turret
Brinell Scale: HBW2.5/62.5 HBW2.5/187.5 HBW5/125 HBW5/750 HBW10/100、HBW10/1500 HBW10/3000 HBW10/250 HBW10/500 HBW10/1000
Testing Force: 62.5kgf(612.9N)100kgf(980.7N)125kgf(1226N)187.5kgf(1839N)250kgf(2452N)500kgf(4903N)750kgf(7355N)1000kgf(8907N)1500kgf(14710N)3000kgf(29420N)
Max Height of Specimen: 200mm
Main Measuring unit: 0.625µm
Net Weight: About 90kg
Power supply: AC220+5%,50~60Hz
Overall Dimension (mm): 550*210*750mm
Duration time: 5~60s
Hardness testing Range: 8~650HBW
Magnification of Microscope: 20X
Carried Standard: GB/T231.2 Chinese Standard, JJG150 Inspection Rule
Distance of Indenter to outer wall: 135mm
Indication of Hardness Value: LCD display, Printer Output, Inside Printer
