1. IMAGING PERFORMANCE
Detector type: UFPA
Spectral range: 8 ÷14μm
Resolution / Pxl size: 80x80 pxl / 34μm
Thermal sensitivity: <0.1 °C @ 30°C
Field of View (FOV): 17° x 17° (9mm lens)
Minimum focal distance: 0.5m
IFOV (@1m): 3.78mrad
Focusing: Manual on lens
Image frequency: 50Hz
Color palettes: 4 (Iron, Rainbow, Grey, Grey Inverted)
Integrated camera: 1.3Mpxl, FOV 59°
2. IMAGING / IR VIDEO DISPLAY
Display type: 2.8” LCD, color 320x240pxl
Infra PiP Fusion: IR image inside Visible
IR/Visible Video: Recording and saving on micro SD card MPEG4 format
Video output: HDMI
Electronic zoom: x1 ÷ x32
3. MEASUREMENT
Temperature range: -20°C ÷ 350°C
Measurement unit: °C, °F, °K
Accuracy: ±2%rdg or ±2°C
Measurement cursors: 3 (MIN, MAX, FIXED)
Laser pointer Class: 2 according with IEC 60825-1
Built-in illuminator: White light LED
Measurement modes: Automatic / Manual
Emissivity correction: 0.01 ÷ 1.00 + internal table with common materials
Measurement features: Automatic correction based on emissivity and reflexed temperature
4. IMAGE STORAGE AND PC INTERFACE
Memory: Micro SD card 8GB
File format: JPEG standard
Memory size: > 2000 images
PC interface: USB 2.0 (for video and image transfer)
5. POWER SYSTEM
Battery type: Rechargeable Li-ION, 3,7V 2000mAh
Charging system: In camera
Battery life: 4 hours of continuous use
External power: External adapter 100/240VAC (50/60Hz)/5VDC
Drop test: 2m
Dimensions (L x W x H): 224 x 77 x 96mm
Weight(battery included): 0.5kg
Accessories provided:
Cavo micro USB per collegamento PC
Headset with microphone
Micro SD Card 8GB
HDMI video cable
ISO9000 calibration certificate
B45
Charger A0045
Rechargeable Battery BAT45
THTLINK
Batteries and user manual
