Type | MHV-50 | |
Testing Forces | N | 9.807, 19.61, 24.52, 29.42, 49.03, 98.07, 196.1, 249.2, 490.3 |
KGF | 1, 2, 2.5, 3, 5, 10, 20, 30, 50 | |
Carriage Control | Automatic(loading/holding-up of loading /unloading) | |
Holding Time | (0~60)s | |
Amplification of the microscope | 100X, 200X | |
Min. graduation value of the test drum wheel | 0.125um | |
Testing field | 1HV~2967HV | |
Lens/Indenter switch | With Motorized Turret | |
Dimension of the X-Y table | Without | |
Movement field of the X-Y table | Without | |
Max. Height of the specimen | 170mm | |
Max. width of the specimen | 130mm | |
Light source | Cold light source | |
Power | 110V/220V, 60/50HZ | |
Objective | The objective 10x, 20x, 40x can be selected according to user’s requirement | |
Standard accessories | Largest test table, “V”Shape test table | |
10X Digital Micro Lens, Level, Adjustable Screw, Vicker Hardness Block, RS232 Interface Line (supply according to modle of instrument) | ||
Dimension | 535X225X580mm | |
Weight | Gross weight: 60Kg Net weight:50Kg | |
