Testing Range: HLD(170~960), HRC(17.9~69.5), HB(19~683), HV(80~1042), HS(30.6~102.6), HRA(59.1~88),HRB(13.5~101.7)
Testing Direction: 360°
Hardness Scales: HL, HB, HRB, HRC, HRA, HV, HS
Testing result on display: HL value and the corresponding value of selected hardness scale.
User defined material: 5 kind. With setting guide
Display: 320x240 true color TFT screen
Indication Error: ±6HLD (D impact device)
To identify probe: automatically, or by manual.
Data Memory: Max 600 groups (relative to impact times 1~32 adjustable)
Power supply: Rechargeable li-battery, 3.7v
charger: 5V/1000mA, charging time 2.5～4.5
Communication port: USB2.0
Size: 130x83x32mm
Weight: 0.6kg
Working Condition:
- Working temperature: -20°C~55°C
- Storage temperature: -20°C~75°C
- Relative humidity: ≤90％
- The surrounding environment requires no vibration, no strong magnetic field, no corrosive medium and no serious dust
Standard Delivery:
- Main unit: 1 PC
- Standard D Impact Device: 1 PC
- Standard Calibration Block: 1 PC
- Standard Support Ring: 1 PC
- Brush: 1 PC
- USB Cable, charger: 1 PC
- PC Software: 1 PC
- User Manual: 1 PC
- Instrument Case: 1 PC
