Huazheng HZ-109S5 Primary Current Injection Tester

Power input: AC: 380V. 75A

Power supply: AC: 220V. 1A, 50Hz/60HZ

Output current: AC:5000A. 5V or 2500A. 10V

LCD display shows current value, ratio and phase angle at one time and two Times.

Primary current range: 0~5500A, resolution: 0.1A,

Two measuring current Range: 0~6A, resolution: 0.001A, accuracy: 0.5%

Accuracy: 0.5%

Use environment: temperature -10~40℃, relative humidity 80%

Host: 430mm × 430mm × 470mm;

External pressure regulator: 515mm × 375mm × 950mm;

Wire box: 385mm × 270mm × 380mm × 2 pieces.

Weight: Host 108Kg, external voltage regulator 120Kg, wire box (2) 55Kg.
