Measuring methodDPD Method
Measuring range0~2/10 mg/L
Measuring cycle2.5min, available of 150sec~999sec
Reproducibility<±3%
Minimum scale unit0.001mg/L
Sample temperatureTemperature : 5 ~ 40℃
Sample inflow velocity200~500mL/min
Reagent replacement cycleOne month (when mixing DPD reagent)
Calibration methodTwo-point calibiation (Low, High), zero memory function
Screen display128*64dot Graphic LCD
Status outputCalibrating, alarm warning, equipment trouble, shutoff of inflow water,
external run/stop, discontinuation of measurement, Cl2 pump in operation
Alarm settingTwo types (high, low), LCD display & buzzer setting
PowerAC 220V, 60Hz, 110V(option)
Weight15kg
Dimension350(W) * 450(D) * 200(H)mm
Inflowing sample
water fittingInflowing sample water fitting : 6 mm
& effluent sample
water fittingEffluent sample water : 6 mm
Self-diagnosis functionLamp, Detector self-checking
Applicable environmentNon-vibration, temperature : 5~40℃, humidity: 90% at 40℃
MountingAvailable of Wall mounting
