Specifications
Rated power (KVA/KW): 15/13.5
Noise level (dBA): 60
Input specification
Nominal voltage (VAC): 207-467
Voltage range (VAC): 207-467
Frequency range (Hz): 46-64
Number of phases: 3P + G + 4W
Output specification
Voltage (VAC): 208/220/230/240 ±1% VAC
Frequency (Hz): Main mode (46 – 54Hz)/ (56 – 64Hz); Battery mode 50 (± 0.1%)Hz/ 60 (± 1%)Hz
Switching time (second): 0 second
Waveform: Standard sine wave
Battery
Quantity and type: 12V x 16VAC
Dimension & Weight
Product dimensions (mm): 248 x 500 x 616 (L x W x H)
Weight: 34kg
Operating environment
Operating temperature: 0ºC – 40ºC
Humidity: 20 – 90% without condensation
