Specifications
Rated power (KVA/KW): 20/18
Noise level (dBA): 60
Input specification
Nominal voltage (VAC): 380/400/415
Voltage range (VAC): 207-476
Frequency range (Hz): 40-70
Number of phases: 3P + G + 4W
Output specification
Voltage (VAC): 208/220/230/240 ± 1%
Frequency (Hz): Main mode (46 – 54Hz)/ (56 – 64Hz; Battery mode 50 (± 0.1%)Hz/ 60 (± 1%)Hz
Switching time (second): 0 second
Waveform: Standard sine wave
Battery
Quantity and type: 16 x 12V
Dimension & Weight
Product dimensions (mm): 248 x 500 x 616 (L x W x H)
Weight: 41kg
Operating environment
Operating temperature: 0ºC – 40ºC
Humidity: 20 – 90% without condensation
