DIMENSIONS AND WEIGHTS:
Dimensions: 6300*1430*1530mm
Required area: 9.45㎡
Weight: ca. 2500 kg
Load per unit area 400 kg/m2: 400 kg/m2
PROCESS CHAMBER HEATING:
Length of heating zones: 3730mm
Quantity of preheating zones: 9
Length of preheating zones: 3450mm
Quantity of peak zones: 1
Warm up time: ca. 30 min
VACUUM ZONE:
Vacuum maximum pressure: 0.1-12kpa
Vacuum pump flow: 1000/min
Pressure relief time: ≦10S
Product time: ≧40S
COOLING ZONE:
Quantity of cooling zones: 3[top 3(Water cooling)/bottom 3(Air cooling)]
Length of cooling zones: 1460mm
CONVEYOR:
Transport Level: 900 ±20 mm
PCB Size: L320 - W400mm
Conveyor control: 3-stage, independent control
Conveyor Number: 1
Adjustable conveyor speed: 300 - 1800 mm/min
INTERFACES:
Type: SMEMA
Voltage supply: 5-Wire System 3P,N,PE 380 VAC ± 5 % 50 Hz ; Other voltages upon request
Connected load: 68KW
Operating capacity: 16 KW
