Output voltage
Rated value (V1): 0 ~ 350V
Settable range: 0 ~ 367.5V
Output current
Rated value (A1): 0 ~ 84A
Settable range: 0 ~ 88.2A
Output power
Rated value: 0 ~ 10kW
Settable range: 0 ~ 10200W
Internal resistance
Adjustment range: 0 ~ 4.1667Ω
Insulation
Primary - Chassis: 2.5 kV DC
Primary - Secondary: 2.5 kV DC
Secondary - Chassis: 750VDC
Operating temperature: 0°C ~ 50°C
Humidity: 30%RH ~ 80%RH (no condensation) Max 80% RH up to 30°C, linear decrease to 50% RH at 40°C
Storage temperature: -20°C ~ 70°C
Input
Input voltage range: 180VAC ~ 460VAC , Optional 480VAC (type:432VAC ~ 528VAC)
Input frequency range: 47Hz ~ 63Hz
Current (Maximum): 40A / Phas (Input 3-phase 180V)
Inrush current (Maximum): 66A / Phas (Input 3-phase 460V)
Input Power (Maximum): 12kVA
Interface
Standard: LAN, J1
Optional: Analog, RS-485, GPIB
Size and Weight
Total (WxHxD): 482 x 132 x 765.1 mm
Weight (kg): 34.8
