Number of stirring positions: 1
Stirring quantity max. per stirring position (H2O): 15 l
Motor rating output: 2 W
Direction of rotation: left
Speed display set-value: scale
Speed control: Turning knob
Speed range: 100 - 2000 rpm
Setting accuracy speed: 10 rpm
Stirring bar length: 20 - 80 mm
Self-heating of the set-up plate by max. stirring (RT:22°C/duration:1h): 28 +K
Heat output: 600 W
Temperature display set-value: scale
Temperature unit: °C
Heating temperature range: 50 - 320 °C
Heat control: scale
Temperature setting range: 0 - 320 °C
Connection for ext. temperature sensor: ETS-D5
Characteristics in the medium with temperature sensor: 1l M50 Oil at H1500
Heating rate medium: 6 K/min
Adjustable safety circuit: 100 - 360 °C
Set-up plate material: technical enamel
Set-up plate dimensions: Ø 135 mm
Dimensions (W x H x D): 160 x 100 x 250 mm
Weight: 2.8 kg
Permissible ambient temperature: 5 - 40 °C
Permissible relative humidity: 80 %
Protection class according to DIN EN 60529: IP 21
Voltage: 230 / 115 / 100 V
Frequency: 50/60 Hz
Power input: 620 W
