Min. detectable leak rate for helium (vacuum method): <5 x 10^-12 mbar l/s
Min. detectable leak rate for helium (sniffer mode): <5 x 10^-8 mbar l/s
Max. inlet pressure (MASSIVE mode): 1000 mbar
Pumping speed during evacuation: >36 m³/h
Helium pumping speed (high sensitive mode ULTRA): 4 l/s
Response time: <1 s
Time until ready for operation: <3 min
Detectable masses (ULTRATEST Sensor Technology) 2, 3, 4 (H2, 3He, He)
Ion source: 2 filaments, iridium/yttria oxide coated
Test port: DN 25 KF
Adjustable triggers: 4
Interface: 2 x USB, Ethernet / LAN
Supply voltage: 100 to 240 V 50/60 Hz (AC)
Power consumption: typ. 700 VA, max. 1500 VA
Dimensions (L x W x H): 1050 x 472 x 987 mm (42 x 21 x 34 in.)
Weight: 132 kg
Permissable ambient temperature range (during operation): 10 to 40°C
Additional Features: HYDRO·S, separate sniffer line SL3000 port
