Direct access to our certified experts
Data output: USB, Bluetooth
Measuring range refer to the specification of transducers
Resolution: 0.01mm
Accuracy:
±0.04mm (H≤10mm)
±(0.04+H/1000)mm (10≤H<10mm)
±H/333mm (H≥100mm)
His measuring thickness in mm
Working gap (the distance between the probe and the measured object): ≤1mm
Gain: automatic and manual gain
Material velocity: 1000-9999 m/s
Measurement frequency: 2 times/second 10 times/second fast measurement mode auto Measuring mode: automode, manual mode
Display: LED, 800x268
Storage: 10000 data stored in 100 files
Power supply: 5V rechargeable lithium battery, 6 hours working time
operation temperature: -10°C-350°C
Dimension: 180x35x34mm
Weight: 300g
SPECIFICATON OF PROBES
Code EMU-B100-T01 (included)
Magnet: permanent magnet
Measuring range: 1.5-150mm
Diameter(Ød): Ø15mm
Working temperature: -10-120°C
Applications
General use, mainly used for fine crystal materials, such as mild steel, aluminum
Code EMU-B100-T02 (optional)
Magnet: permanent magnet
Measuring range: 1.5-300mm
Diameter (Ød): Ø25mm
Working temperature: -10-600°C
Application: High temperature environment, mainly used for ferromagnetic fine crystal materials, such as mild steel
STANDARD DELIVERY
Main unit: 1 pc
Normal temperature probe: 1 pc
calibration block(8mm): 1 pc
USB cable: 1 pc
■ Measurement without ultrasonic coupling agent, for workpieces with surface temperatures less than 600°C (depending on the probes)
■Compact size, easy to carry, comes with waveform display and full-function keyboard, easy to adjust the measurement parameters
■ Non-contact measurement of rough, corroded surfaces without sanding
Storage of 10000 data and 100 files
■ Highly intelligent functions such as alarm for exceeding upper and lower limits, automatic zero calibration, automatic identification of probes, etc
■ Automatic power off
■ Suitable for inspection of workpieces of various shapes, such as pipes, small tubes, elbows, etc
Datasheet
