Type: manual switch of test force
Test force: 0.098N (10gf), 0.245N (25gf), 0.49N (50gf), 0.98N (100gf), 1.96N (200gf), 2.94N (300gf), 4.9N (500gf), 9.8N (1kgf)
Vickers scales: HV0.01, HV0.025, HV0.05, HV0.1, HV0.2, HV0.3, HV0.5, HV1
Knoop scales: HK0.01, HK0.025, HK0.05, HK0.1, HK0.2, HK0.3, HK0.5, HK1
Range: 8HV~2900HV/HK
Length measurement resolution: 0.01µm
Objective/indenter switch: motor driven turret
Stage lifting: manual
Load control: automatic (load/dwell/unload)
Load dwell time: 1~99 second
Objective: 10X, 40X (optional 20X, 50X, 60X)
Eyepiece: 10X
Total magnification: 100X (for measurement or observation), 400X (for measurement)
Max. workpiece height: 100mm
Max. testing width: 130mm (from the center of indenter to the wall of main body)
X-Y stage:dimensions: 100×100mm, travel range: 25×25mm
Data output: built-in printer, RS232
Power supply:220V, 50/60Hz
Dimension: 540×260×650mm
Weight: 50kg
Standard Delivery
Main unit: 1 pc
10X, 40X objective: 1 pc of each
Knoop indenter: 1pc
Hardness test block 400~500HV0.2: 1 pc
Hardness test block 700~750HV1: 1 pc
Hardness test block 700~800HK1: 1 pc
Level: 1 pc
Touch pen: 1 pc
Slice holder: 1 pc
Vice: 1 pc
Cylinder holder: 1 pc
Anti-dust cover: 1 pc
