Test force: 0.01; 0.025; 0.05; 0.1; 0.2; 0.3; 0.5; 1kgf
Vickers scales: HV0.01; HV0.025; HV0.05; HV0.1; HV0.2; HV0.3; HV0.5; HV1
Stage elevation: manual
Load control: automatic (load/dwell/unload)
Load dwell time: 5~60 sec (5 second increment)
Objective: 10X, 40X
Eyepiece: 15X
Total magnification:
-150X (for observation)
-600X (for measurement)
Max. workpiece height: 160mm
Max. workpiece depth: 140mm (from the center of indente)
X-Y stage:
-Dimension: 100x100mm
-Travel range: 25x25mm
-Graduation: 0.01mm
Data output: RS232C
Power supply: 110/220V, 50Hz
Dimension: 540x500x640mm
Weight: 50kg
Standard delivery:
-Main unit: 1pc
-10X, 40X objective: 1pc of each
-Micro Vickers indenter: 1pc
-Hardness test block 400~500HV0.2: 1pc
-Hardness test block 700~800HV1: 1pc
-Slice holder: 1pc
-Vice: 1pc
-Cylinder holder: 1pc
-Level: 1pc
-Anti-dust cover: 1pc
Optional accessory:
-20X objective
-Hardness test block 400~500HV0.2
-Hardness test block 700~800HV1
-Measuring system
-Camera adpater
