Specification
Circumferential magnetizing currentAC: 0~2000A
Longitudinal magnetization potential:AC: 0~12000AT
Electrode spacing:100~600mm adjuctable (manual)
Magnetization sensitivity: 15/50 clearly displayed on A sensitivity test piece
Duty cycle≥25%, continuous magnetization time maximium 3s
Magnetization method:circumferential magnetization, longitudinal magnetization, compound magentization
Clamping method:pneumatic clamping
Running mode:pneumatic/manual
Electrode plate:Ø160mm
Magnetizing coil:coil inner diameter Ø200mm two, coil turns 6 turns
Demagnetization:automatic attenuating demagnetization, residual magnetism ≤0.3mT
UV (Light) Lux:≥2000uW/cm² (calibration at the distance of 381mm)
Power supply:380V three-phase alternating current, 50Hz
Air supply: 0.4~0.7MPa
Operation environment:temperature: -5~45°C, relativehumidity: ≤90%
Dimension (LxWxH):main unit: 2600x850x1700mm, including darkroom dimension: 2800x1600x2200mm
Weight:700kg
Standard Delivery
Electrical control system:1pc
Magnetized power system:2pc
Spray system:1pc
Magnetic suspension recovery device:1pc
Ultraviolet flaw detection lamp:1pc
Demagnetization system:1pc
