Test condition:Suitable for NSS (Neutral), AASS (Acid), CASS (Copper Accelerated) test
Work chamber dimension (WxHxD):1600x850x550mm
Work chamber volume:740L
Saline tank volume:90L
Work chamber temperature:(NSS, AASS) Test temperature: 35°C±1°C / (CASS) Test temperature: 50°C±1°C
Saturated barrel temperature:(NSS, AASS) Test temperature: 47°C±1°C / (CASS) Test temperature: 63°C±1°C
Saline temperature:(NSS, AASS) Test temperature: 35°C±1°C / (CASS) Test temperature: 50°C±1°C
Heat type:thermal radiation heat
Test fluid:NSS: pure water +NaCl (pH 6.5~7.2), AASS: pure water +NaCl+CH3COOH (pH 3.0-3.3), CASS: pure water+NaCl+CuCl2 (pH 3.0~3.3)
Compressed air pressure:0.6MPa
Power:4kW
Electricity supply:AC 220V, 1Ø, 50HZ
External dimension (WxHxD):2300x1150x1550mm
Weight (advanced type):480kg
Standard Delivery
Main unit:1pc
Sample holder:1group
Sodium chloride NaCl:2bottles
10L salt water preparation cup:1pc
80cm2 collection cup:2pcs
50cm glass measure cylinder:2pcs
■ Adopting plastic precision nozzle and cone spraying device, even mist falling, fast, Long nozzle life, no crystallisation
■ Spraying time can be controlled internally without the need for an external time relay
■ Adjustment of brine flow and compressed air pressure by means
of a flow meter and a high-pressure valve to ensure uniform salt spray deposition
■ Adopt manual water filling system, water level is insufficient to automatically replenish the function, to ensure that the test is not interrupted
■ USB port for download curves and historical data
