Max. test force: 300KN
Accuracy: ±1%
Test force measurement range: 2%-100%FS
Resolution of test force measurement: 1/300000 of Max. test force (same resolution all the way)
Deformation measurement device: extensoment
Deformation measurement range: 1%-100%FS
Deformation measurement accuracy: ±1%
Deformation measurement resolution: 1/300000
Displacement accuracy: ±1%
Displacement resolution: 0.01mm
Displacement travel: 200mm
Max tensile space (including piston stroke): 600mm
Max compression space (including piston stroke): 500mm
Transmission mode: Chain drive
Safety protection device: Software protection and mechanical limit protection
Control function: Special software, closed-loop of stress, strain and velocity
Clamping range of round sample: Ø10-32mm
Clamping range of flat sample: 0-15mm
Upper and lower pressure plate size: Ø188mm
Bending branch roll width: 140mm
Total power: 2.5kW
Power supply: 380V, 50Hz
Demension(mm): Host:800x620x1900, Oil source:1140X600x855
Weight: 2T
