AEP Transducers DME2 デジタル圧力計 (RV; 2.5bar)

Type: RV

Full Scale: 2.5 bar

Display: 2.500 bar

Resolution: 0.001 bar

Accuracy (Linearity And Hysteresis) : ≤ ± 0.20 % F.S.

Pressure Units Bar (Other Units On Request): °C

Temperature Indication:

A) Resolution: 0,1 °C

B) Accuracy: ± 1 °C

Reference Temperature: 23 °C

Operating Temperature: 0 / +70 °C

Storage Temperature: -10 / +80 °C

Relative Humidity: < 90 % not condensed

Temperature Effect (1 ° C):

A) On Zero: ≤ ± 0.002 %

B) On Sensitivity: ≤ ± 0.002 %

Red Display Highly Efficient: 7 segmenti

Number Of Digits: 4

Display Height: 14 mm

Internal Resolution: 16 bit

Readings Per Second Programmable: 50 (20ms)

Digital Filter Programmable: 0 ÷ 5

Resolution Programmable: 1, 2, 5, 10

Zero Function: 1

Peak Function: Active in the POSITIVE /NEGATIVE RANGE

Setpoint Parameter Protection: Via Password

Set Point Programmable: 2

Rele’ Output With Exchange Contacts: 2

Max Tension To The Contacts: 24 Vdc

Max Current: 500 mA

Max Power: 12 W

External Power Supply: 24 Vdc

Power Supply Range: 18 … 26 Vdc

Max Current Consumption: 120 mA

External Electrical Connections: Sub Db9 Female

Mechanical Limit Values::

A) Service Pressure: 100% F.S.

B) Limit Pressure: 150% F.S.

C) Breaking Pressure: >300% F.S.

D) Highly Dynamic Pressure: 75% F.S.

Process Coupling : 1/2" G Maschio

Seal Recommended : USIT A 63-18

Tightening Wrench: 27 mm

Tightening Torque: 28 Nm

Protection Class (En 60529): IP65 front panel

Sensor Execution Material: INOX 17-4 PH

Case Execution Material: ALLUMINIO
