Ceyear 3671G ベクトルネットワークアナライザー (10MHz~43.5GHz)

Frequency Range: 10 MHz to 43.5 GHz

Frequency Resolution: 0.1Hz

Frequency Accuracy : ±1×10-7 (23℃±3℃)

Max. Output Power

•   10MHz – 50MHz: +12dBm •   50MHz – 250MHz: +13dBm

•   250MHz – 1GHz: +13dBm •   1GHz – 10GHz: +13dBm

•   10GHz – 20GHz: +10dBm •   20GHz – 35GHz: +8dBm

•   35GHz – 43.5GHz: +3dBm

Power Sweep Range

•   10MHz – 50MHz: 30dB •   50MHz – 10GHz: 33dB

•   10GHz – 20GHz: 30dB •   20GHz – 35GHz: 28dB

•   35GHz – 43.5GHz: 28dB

Dynamic Range

•   10MHz – 50MHz: 90dB •   50MHz – 250MHz: 98dB

•   250MHz – 1GHz: 115dB •   1GHz – 10GHz: 128dB

•   10GHz – 20GHz: 122dB •   20GHz – 35GHz: 118dB

•   35GHz – 43.5GHz: 110dB

Effective Directivity: 42dB (10MHz – 2GHz),  45dB (2GHz – 20GHz),  38dB (20GHz – 43.5GHz)

Effective Source Match: 40dB (10MHz – 2GHz),  30dB (2GHz – 20GHz),  30dB (20GHz – 43.5GHz)

Effective Load Match: 42dB (10MHz – 2GHz),  45dB (2GHz – 20GHz),  36dB (20GHz – 43.5GHz)

Port Connection: 2.4mm (male)

System Impedance: 50Ω

Number Of   Measuring Ports: 2/4 ports

Peripheral Interface: USB,GPIB,VGA,LAN,HDMI interface

Operating System: Windows 7

Display: 12.1inch 16:10 screen (Equipped with   capacitive touch function)

Size

• 2-Port Instrument:

W´H´D≈426mm×266mm×400mm(No   soles, no handles)

W´H´D≈516mm×280mm×490mm(include   soles and handles)

• 4-Port Instrument:

W´H´D≈426mm×266mm×450mm(No   soles, no handles)

W´H´D≈516mm×280mm×540mm(include   soles and handles)

Max. Power   Consumption: 300W

Power Supply: 50Hz 220V or 50Hz/60Hz  110V AC

Max. Weight: 28kg

See more detail information in the Datasheet
