NI PXI-6123 PXI Multifunction I/O Module (500 kS/s/ch, 16 bits, 32 MS)
生産者: NI Model: PXI-6123 P/N: 779180-01 - 連絡先
Call for the best price
Hanoi city: (024) 35.381.269
Danang city: (023) 63.747.711
Bac Ninh city: (0222)730.39.68
HCM city: (028) 38.119.636
Bus Connector: PXI Hybrid
Maximum Number of Single-Ended Analog Input Channels: 0
Maximum Number of Differential Analog Input Channels: 8
Simultaneous Sampling: Yes
Maximum Sample Rate: 500 kS/s/ch
Analog Input Resolution: 16 bits
Analog Input Absolute Accuracy: 4960 μV
Number of Analog Output Channels: 0
Maximum Update Rate: —
Number of Bidirectional Digital Channels: 8
Current Flow Direction: —
Number of Counters/Timers: 2
Electrical Signal Measured: Voltage
Analog Input FIFO Buffer Size: 32 MS
Provides a mix of analog I/O, digital I/O, counter/timer, and triggering functionality in a single PXI module.
The PXI Multifunction I/O Module provides I/O with varying numbers of channels, sample rates, and output rates with precise timing, triggering, and synchronization between models. This module can be used for industry applications such as laboratory research, design verification test, and manufacturing test.The PXI Multifunction I/O Module includes the NI-DAQmx driver and configuration utility that simplify configuration and measurements. NI-DAQmx supports NI programming environments as well as Python, ANSI C, C#.NET, and MathWorks MATLAB® software.
Datasheet
