OMEGA IDRN-FP DIN Rail Conditioners with Model Specific Input | Dig. Out option (Frequency, Pulse, 0 to 400 mV to 0 to 400 Vac, 0 to 50 kHz)
生産者: OMEGA Model: IDRN-FP - 連絡先
Call for the best price
Hanoi city: (024) 35.381.269
Danang city: (023) 63.747.711
Bac Ninh city: (0222)730.39.68
HCM city: (028) 38.119.636
Width: 25 mm
Height: 90 mm
Length: 107 mm
Accuracy: ± 0.1 %
Mounting: DIN Rail 35 mm Standard
Isolation: 1800 Vdc
Input Type: Frequency, Pulse
Resolution: 15 to 19 Bit
Output Detail: 0 to 10V @ 10 mA max 0 to 20 mA or 4 to 20 mA, 10V compliance
Supply Voltage: 10 to 32 Vdc
Input Range Note: FP Default Settings iDRN:;Input 0 to 20 KHz; Output 4 to 20 mA ;(custom settings available at no charge)
Number of Inputs: 1
Electrical Output: 4 to 20 mA
Power Consumption: 2.4 W
Supply Power Type: DC
Excitation Voltage: 5, 8.2, 12.5 Vdc
Voltage Output Range: 0 to 10V
Storage Temperature, Max: 85 °C
Storage Temperature, Min: -40 °C
Voltage Measurement Range: 0 to 400 mV to 0 to 400 Vac
Operating Temperature, Max: 55 °C
Operating Temperature, Min: -5 °C
Frequency Measurement Range: 0 to 50 kHz
