RADWAG AS 3100.X7 分析天びん (3.1kg, 1mg)

Metrological parameters

Maximum capacity [Max]: 3.1kg

Minimum load:

Readability [d]: 1 mg

Verification unit [e]:

Tare range: 3.1 kg

Standard repeatability [5% Max]: 0.5 mg

Standard repeatability [Max]: 0.6 mg

Standard minimum weight (USP): 1g

Standard minimum weight (U=1%, k=2): 100 mg

Permissible repeatability [5% Max]: 0.8 mg

Permissible repeatability [Max]: 1 mg

Linearity: ±4 mg

Stabilization time: 2s

Adjustment: internal (automatic)

OIML Class:

Physical parameters

Leveling system: semiautomatic  LevelSENSING

Display: 7″ graphic colour touchscreen

Weighing chamber door: manual

Delivery components: Balance, weighing pan, weighing pan shield, centring ring, bottom cover, power supply, fabric dust cover

Weighing chamber dimensions: 190×190×222mm

Weighing pan dimensions: ø90 mm (openwork pan)

Net weight: 7. 3 kg

Gross weight: 9.3 kg

Protection class: IP 43

Touchfree operation: 2 IR Sensors

Communication interface

Communication interface: RS232¹, 2×USBA (interchangeable), USBB, WiFi®, Ethernet

Electrical parameters: Power supply

Adapter: 100 – 240V AC 50/60Hz 0.6A; 12V DC 1.2A

Balance: 12 – 15V DC 0.8A max

Power consumption max.: 4 W

Operating temperature: +10 — +40 °C

Ambient conditions monitoring (option): THBR 2.0 System, THBR BOX, THB P, THB W, THB S

Relative humidity: 40% — 80%
