Nominal Power: 370W
Peak power (Tool): 150W/Tool
Selectable temperature: 90 to 450 ºC / 190 to 840 ºF
Idle temp. stability (still air): ±1.5 ºC / ±3 ºF (Meets and exceeds IPC J-STD-001)
Temperature accuracy: ±3 % (Using reference cartridge)
Temp. adjustment: ±50 ºC / ±90 ºF (Through station menu setting)
Tip-to-ground resistance: <2 ohms
Tip-to-ground voltage: <2 mV RMS
USB-A:
Firmware update
Graphics and profiles
USB-B: PC communications
FAE / Robot connector: Remote control or FAE Fume Extractor connection
Control Unit: 232 x 148 x 120 mm / 7.16 kg / 9.13 x 5.83 x 4.72 in / 15.78 lb
Package: 545 x 345 x 275 mm / 10.40 kg./ 21.46 x 13.58 x 10.83 in / 22.93 lb.
