JTSE CONTROL UNIT
Peak power: 700W
Selectable temperature: 150 to 450 °C / 300 to 840 °F
Air flow regulation: 5 to 50 SLPM
Vacuum: 30% / 228 mmHg / 9 inHg
Profiles: 25 (up to 10 steps for each), 1 preset profile
Type K TC connector: 1 for Control & Protection
ESD safe: Meet ANSI / ESD S20.20-2021
USB-A:
Firmware update
Graphics and profiles
USB-B: PC communications
Robot connector: Remote control or FAE Fume Extractor connection
PHSE PREHEATER
Peak power: 600W
Selectable temperature: 50 to 250ºC / 120 to 482ºF
Heating area:
65 x 135 mm / 2.6 x 5.3 in - 1 zone
130 x 135 mm / 5.1 x 5.3 in - 2 zones
Type K TC connector: 4 for control & protection
Profiles: 22 (up to 6 steps for each), 3 preset profiles
Maximum work time: 600 min. or indefinite
ESD safe: Meet ANSI/ESD S20.20-2021
USB-A:
Firmware update
Graphics and profiles
USB-B: PC communications
Robot connector: Remote control
Aux. connector: Console connection
WEIGHT AND DIMENSIONS
Control Unit: 232 x 148 x 160 mm / 16.59 kg. (9.13 x 5.83 x 6.30 in / 36.57 lb.)
Package: 700 x 410 x 390 mm / 23.10 kg. (27.56 x 16.14 x 15.35 in / 50.93 lb.)
