- Temperature 1) (bath fluid : ethylene glycol mix 1:1 water)
+ Working temperature range (℃ / ℉): -20 to 80 / - 4 to 176
+ Temperature stabilityat 15℃ (±℃ / ℉): 0.1 / 0.2
- Cooling capacity(bath Fluid : ethylene glycol mix 1:1 water)
+ at 80℃ (kw): 3.5
+ at 40℃ (kw): 2.4
+ at 20℃ (kw): 2.5
+ at 0℃ (kw): 1.1
+ at -20℃ (kw): 0.4
- Heating capacity(kw): 4
- Pump
+ Max. flow rate(L / min, gal / min): 40 / 10.6
+ Max. pressure (bar / psi): 3.3 / 47.9
- Dimension
+ Max. filling capacity (L, cu ft):25 / 0.88
+ For tubing dia. (mm / inch): 20 / 3/4
+ Filling inlet (Ø, mm / inch): 120 / 4.7
+ Overall (WxDxH, mm / inch): 550×900×1140/ 21.7×35.4×44.9
+ Net weight (kg / Ibs): 142 / 313
- Electric requirement (230V, 60Hz): 27A
