Accuracy level: 0.5
Effective measuring force range: 0.4% ~ 100%
Force measurement accuracy: ±0.5% of the indicated value
Resolution: the maximum load is 1/± 25,000 yards, the inside and outside are not classified, and the whole resolution is unchanged
Effective test width: 150mm
Effective drawing space: 650mm/800mm/1000mm
Test speed range: 0.5 ~ 500mm/min
Displacement measurement accuracy: within ± 0.5% of the indicated value
Test bench safety device: electronic limit protection
Test bench return function: manual or automatic selection, automatic or manual return to the initial test position after the test
Overload protection: when the maximum load exceeds 10%, the machine will be automatically protected
Fixture configuration: One set of fixtures
Host size: 420×350×1520mm
Motor: 220V±10% 0.2kW /0.4KW imported servo motor
Main engine weight: about 50 Kg
Optional capacity: 2,5,10,20,50,100,200 kg, maximum 200kg
Basic configuration
One monitor and one host
One computer
One set of standard fixtures
