-Typical Performance Characteristics - at 20 degrees C
-Antenna Input:
Connector: MCX Socket - 50 Ohm
Input Frequency Range: 1MHz – 7200MHz (7.2GHz)
Sensitivity 100MHz: -47dBm
200MHz: -47dBm
500MHz: -46dBm
1GHz: -41dBm
2GHz: -29dBm
5GHz: -8dBm
7.2GHz: -3dBm
Demodulation Sensitivity for 50mW Audio: -30dBm (meas'd at 500MHz 50% AM 1kHz)
Frequency Response: 400Hz - 5kHz +/-2dB
-INSTRUMENT DISPLAY:
Type: LCD STN Backlit
RF Signal Strength: 10 element bargraph
RF Carrier Frequency: 2560.0MHz (2.56GHz) maximum
-INTERNAL AUDIO AMPLIFIER:
Output Power: 0.25W
Frequency Response: 300Hz - 15kHz +/-1dB
Headphone Connector: 3.5mm Jack
-MISCELLANEOUS:
Internal Battery: 7.2V 650 mAH Li-Ion rechargeable
Operating Duration - Fully charged battery: 8 hours
Charge Time - using supplied charger: 3 hours maximum
Operating Temperature Range: -10 to +50 degrees C
Relative Humidity: < 90%
Dimensions: 114mm x 69mm x 25mm
Weight: 245 g
Signal Processing and Control: RISC Based Microcontrolle
SUPPLIED ACCESSORIES:
• Semi-Rigid Wideband Whip Antenna
• Flexible Wideband Whip Antenna
• Earphones
• 9V DC Charger - 110V to 240V AC input (Auto Switching) with International Adaptors
• Protective Carry Case
