Substrate specification: 01005 and above
Trimming range: 1Ω-1MΩ
Trimming accuracy: 0.1% and 1%
Kerf width: 8-15μm
Laser source: JPT-UV
Measurement channels: 192/240
Laser Trimmer is mainly used to scan and trim resistors with the short-pulse laser. The laser can “cut out” kerfs of given depth by gasifying the resistive film on the ceramic substrate, altering the length and the cross-sectional area of the resistor and this subsequently changes its resistance value.
