Capacity of work tank: 2900x1700x800mm
Work table size: 2250x1100mm
Longitudinal travel(X-axis): 1550(SM)775(DM)mm
Cross travel(Y-axis): 1000mm
Z axis travel(Z-axis+W-axis): 600mm
Distance between platen to table: 720~1320mm
Max. Electrode weight: 500kgs
Max. Work piece weight: 10000kgs
Fluid tank capacity: 4700L
Machine outside dimensions(WxDxH): 6500x4600x3570mm
Machine weight: 15000kgs
Max. Machining current: 120A
Max. Power input: 13KVA
Max. Machining rate: 800 mm3/min
Min. Electrode wear ratio: 0.15%
Best surface / Ra: Ra 0.2μm
Min. D. R. O. resolution(mm): 0.005mm
