Performance Data Temperature
Temperature range [°C]: +4...100
Temperature variation at 37 °C [± K]: 0.4
Temperature fluctuation at 37 °C [± K]: 0.1
Recovery time after 30 seconds door open at 37 °C [min]: 3
Electrical data
Rated Voltage [V]: 200…240
Power frequency [Hz]: 50/60
Nominal power [kW]: 0.8
Unit fuse [A]: 10
Phase (Nominal voltage) [ph]: 1~
Outer dimensions
Width net [mm]: 860
Height net [mm]: 1025
Depth net [mm]: 655
Wall clearance back [mm]: 100
Wall clearance sidewise [mm]: 240
Doors
Inner doors: 1
Unit doors: 1
Internal Dimensions
Width [mm]: 600
Height [mm]: 765
Depth [mm]: 355
Further Dimension
Interior volume [L]: 163
Net weight of the unit (empty) [kg]: 102
permitted load [kg]: 120
Load per rack [kg]: 30
Environment-specific data
Energy consumption at 25 °C [Wh/h]: 80
Energy consumption at 37 °C [Wh/h]: 80
Sound-pressure level [dB(A)]: 48
Fixtures
Number of shelves (std./max.): 2 / 10
