Model: PST
Load capacity : 5T
Recommended input voltage ( excitation, recomended ) : 10~12 V
Maximum input voltage ( excitation, max): 15 V
Accuracy class : 0.03
Resolution ( rated output ) : 400∓20(200~300kg, 1.2~10t) Ω
Non-linearity: 0.03 %FS
Hysteresis error: ∓0.03 %FS
Combined error: ∓0.03 %FS
Non-repeatability: ∓0.02 %FS
Latency (Creep error 30minutes): ±0.03% F.S
Input resistance : 400∓20(200~300kg, 1.2~10t) Ω
Output resistance : 352∓3 Ω
Insulation resistance : 5000 Ω
Operating temperature ( temperature, operating ): -30~+70 oC
Cable length: 2.6m(20~1000kg), 3m(1.2~10t) m
Protection class: IP65
Material made: Aluminum
Safe overload: 120 %FS
Ultimate overload: 200 %FS
Zero Balance: ∓1 %FS
TCO: 0.02 %F.S/10oC
TC SPAN: 0.02 %F.S/10oC
