Frequency range: 100 MHz – 18 GHz
Gain, S21: 25 dB
Flatness: (+/-) 1.5 dB
Noise figure: 7 dB (0.1 - 0.5 GHz)
6 dB (0.5 - 4 GHz)
4.5 dB (4 - 18 GHz)
Input return loss: 15 dB (0.1 – 4 GHz)
10 dB (4 – 18 GHz)
Output return loss: 15 dB (0.1 – 4 GHz)
10 dB (4 – 18 GHz)
Harmonics (@ +4 dBm output power): –30 dBc (typical)
Impedance: 50 Ohms (typical)
Survival input power (max): +15 dBm
Reverse isolation: –50 dB (typical)
Power dissipation: 2.1 W (typical)
Third Order Intercept: (TOI) 23 dBm (typical)
Temperature (operating): –45° C ~ +55° C
(storage) –65° C ~ +85° C
