Bandwidth: 1 GHz
Rise time: ≤450 ps
Input channels: 2
Maximum sample rate: 5 GSa/s half channels, 2.5 GSa/s all channels
Maximum memory depth: 4 Mpts half channels, 2 Mpts all channels
Display size and type: 8.5-inch capacitive touch gesture-enabled display
Waveform update rate: >1,000,000 waveforms per second
Input impedance: Selectable 1 MΩ ± 1% (14 pF), 50 Ω ± 1.5%
Input sensitivity range: 1 mV/div to 5 V/div 2 (1 MΩ), 1 mV/div to 1 V/div (50 Ω)
Vertical resolution: 8 bits
Maximum input voltage: 125 Vrms; 190 Vpk
