• Basic accuracy (50/60 Hz): 0.05% of reading
• Best power accuracy (50/60 Hz): 0.1% of reading
• Power Channels (Voltage and Current): 2 Channels
• Voltage Measurement Bandwidth (-3 dB): 2.5 MHz (-3 dB)
• Current Measurement Bandwidth (2 A or 50 A Input): 100 kHz (-3 dB)
• Current Measurement Bandwidth (External Input): 2.5 MHz (-3 dB)
• Display: 12.1-inch capacitive multi-touch/gesture enabled
• Resolution: 800 (H) x 600 (V) pixel format (screen area)
• Connectivity: USB 2.0
• Power line consumption: Maximum 180 VA
• Power voltage range: 100-240 V, 50/60 Hz ±10%; 100-120 V, 50/60/400 Hz; auto-ranging
• Dimensions: 426 mm W x 308 mm H x 272.8 mm D (16.8 in W x 12.1 in H x 10.7 in D)
• Weight: Net: 11.4 kg (25.2 lbs), Shipping: 12.8 kg (28.3 lbs)
