- Voltage DC: 600 mV, 6 V, 60V, 600V /0.5%
Resolution: 0.1mV, 0.001 V, 0.01 V, 0.1 V
- Voltage AC True RMS : 600 mV, 6 V, 60V, 600V /1%
Resolution: 0.1 mV, 0.001 V, 0.01 V, 0.1 V
- Resistance: 600Ω, 6kΩ, 60kΩ, 600kΩ, 6MΩ, 60MΩ /0.9%
Resolution: 0.1Ω, 0.001kΩ, 0.01kΩ, 0.1kΩ, 0.001MΩ, 0.01 MΩ
- Diode: 2 V/ 0.9%
Resolution: 0.001 V
- Current DC: 60 μA, 600 μA, 6 A, 10 A /1.0%
Resolution: 0.01 μA, 0.1 μA, 0.001 A, 0.01 A
- Current AC: 60 μA,600 μA, 6 A, 10 A /1.5%
Resolution: 0.01 μA, 0.1 μA, 0.001 A, 0.01 A
- Capacitance: 1000 nF, 10 μF, 100 μF, 1000 μF, 10 mF /1.9%
Resolution: 1 nF, 0.01 μF, 0.1 μF, 1 μF, 0.01 mF
- Thermal type k: –40oC to 1372oC (Option)
Resolution: 0.1oC/ 0.1oF
- Frequency: 99.99 Hz, 999.9 Hz, 9.999 kHz, 99.99 kHz /0.1%
Resolution: 0.01 Hz, 0.1 Hz, 1 Hz, 10 Hz
- Built-in: Flash light
- Built-in: Noncontact voltage
- Zlow - Low impedance mode: yes
- PC connectivity: IR-USB (option)
- Connectivity: IR-to-Bluetooth (option)
Power supply: Battery 4 x 1.5 V AAA
Dimensions: (H x W x D): 169 mm x 86 mm x 52 mm
Included Accessories: Test Lead Set; Quick Start Guide; 4 x 1.5 V Batteries; Certificate of Calibration
Datasheet
Brochures
Optional Accessories
U1167A: Test lead, 4mm tips probes; CAT III 1000 V, CAT IV 600 V, 15 A
U1186A: Thermocouple (K-type, 1m) and adapter
U1176A: LED flash light
U1174A: Carrying case, soft
U1171A: Magnetic hanging kit
U1169A: Test Probe Leads (with 19-mm tips and 4-mm tips)
U1177A: Infrared (IR)-to-Bluetooth class 2 (10meter) adapter
U1166A: Test lead
U1168B: Test lead kit
U1117A: Infrared (IR)-to-Bluetooth class 1 (100meter) adapter with Mfi
U1115A: Bluetooth class 1 (100meter) remote logging display
U1118A: Remote connectivity kit (100meter) with U1115A and U1117A
U1173B: IR-USB cable, all U1200 series handheld multimeter VOLT: DC 3.3V - 5V
