Power Supply
- Battery: Large capacity lithium battery
- Power Adapter:
+ Input： AC100～240V，50/60Hz，0.7A
+ Output： DC15V，1.66A
Power consumption
Power consumption: ≦6W
Working power supply: Continuous work for more than 10 hours
Optical Ethernet communication port
Model: 100Base-FX (100M Full duplex optical fiber network)
Port Type: LC
Wavelength: 1310nm
Transmission distance: ≧1km
Application: IEC61588 Times and other network messages
Optical serial port communication interface
Port number: 2 pcs
Port Type: ST
Wavelength: 62.5/125μmMultimode fiber，Wavelength850nm
Transmission distance: ≧1km
Application: Receive/Send IEC60044-7/8（FT3），IRIG-B Timing signal transceiver
Analog input communication interface
Port number: 1 pair
Port Type: Rubber terminal
Hard contact input/output communication interface
Port number: 2 pairs
Port Type: Aviation socket to rubber terminal
TF card slot interface
Port number: 1 pc
Application: TF card for importing the whole station configuration file , recording documents, storing / exporting test reports and upgrading software.
Analog input communication interface
Port number: 1 pair
Time signal
IRIG-B: Time accuracy<1us typ I
EC 61588: Time accuracy<1us typ
Mechanical parameters
Display screen: 4.3’touch LCD screen
Size: 176×100×58 mm
Weight: ≦0.75kg
Temperature range
Altitude: ≤5000m
Ambient temperature: Normal operating temperature：-10～55℃
Storage and transportation：-25～85℃
Relative humidity: 5％～95％
Atmospheric pressure: 60～106KPa
