Measuring rate: ≤10 kHz
Limit frequency: ≤1 kHz
Accuracy: ≤±0.05 % f.s.
Min./max. peak detection: 1 ms
Reaction on threshold exceeding: 1 ms
Operating temperature range (rated): 10 ~ 60 °C
Service temperature range: -10 ~ 60 °C
Storage temperature range: -25 ~ 80 °C
Measured value storage: ring buffer for up to 5,000 measured values
Input power:
Voltage: 100 ~ 240 VAC
Frequency: 50 ~ 60 Hz
Housing material: Aluminium
Dimensions:
Width: 260 mm
Height: 2 HE
Weight: ≈ 2 kg
Display
4×20 character LC display: max. 7-digit per value
Keyboard: membrane keypad, 7 keys
Menu language: German / English / French / Italian / Spanish
Sensor inputs
Torque and force transducer:
Strain gage full bridge: 0.5 ~ 3.5 mV/V
4-/6-conductor techniques
Supply (sensor): 5 V (50 mA)
Torque transducer:
Supply: ±5 VDC, ±10 VDC
Frequency: ≤300 kHz
Supply: 24 V (700 mA)
Speed input: TTL ≤300 kHz
Angle of rotation input: TTL ≤300 kHz
Control signals, analog output, interface
8 digital logic I/O signals, each:
Output signal: open collector
Input signal: TTL or 24 VDC
Analog output 1:
Torque / load: ±10 VDC
With update rate: 10 kHz
Analog output 2:
Torque / speed / angle: ±10 VDC
With update rate: 1 kHz
Analog output 3:
Mechanical rating: ±10 VDC
With update rate: 1 kHz
Interface: USB 2.0
Communication port: RS-232C, ≈115 kbps
