NI NI-9485 C Series Relay Output Module (Conformal Coated, Solid State FET, 8-Ch, 30 VAC, 60 VDC)
생산업체: NI Model: NI-9485 P/N: 779600-02 - 연락처
Call for the best price
Hanoi city: (024) 35.381.269
Danang city: (023) 63.747.711
Bac Ninh city: (0222)730.39.68
HCM city: (028) 38.119.636
Relay Type: Solid State FET
Number of Digital Output Only Channels: 8
Maximum Switching Voltage AC: 30 V
Maximum Switching Voltage DC: 60 V
Front Connection Type: Screw Terminal
Conformal Coated: Yes
Enclosed: Yes
Supported Hardware Platform: CompactDAQ CompactRIO
Provides output signals from electromechanical and solid state/FET relays for CompactDAQ or CompactRIO systems.
The C Series Relay Output Module enables you to switch up to eight signals at 60 V maximum DC switching voltage and up to 250 V of maximum AC switching current. For quick reference, every channel features an LED to indicate the state of that channel. The C Series Relay Output Module allows for direct connection to a wide array of industrial devices such as motors, actuators, and DC devices.The C Series Relay Output Module includes the NI-DAQmx driver and configuration utility that simplify configuration and measurements. NI-DAQmx supports NI programming environments as well as Python, ANSI C, C#.NET, and MathWorks MATLAB® software.
