1)Measurement ofinsulation resistance
Testvoltage:500V/1000V/2500V/5000V10000V/12000V
Resolutionresistance measurement:500GΩ/1TΩ/2.5TΩ/35TΩ
Accuracy:± 5%rdg| ±and± 20%rdg3dgtdepending onresolution
Shortcircuitcurrent:5mA
2)the output voltage
Power voltage:500V/1000V/2500V/5000V10000V/12000V
Accuracy:0 ~+20%
Solutionschosen:
50 ~600V(step5V),
610~1200V(10Vstep),
1225~3000V(25Vstep)
3050~6000V(50Vstep)
6100~10000v(step100V)
12000V10100~(100 Vstep)
3)Measure the voltage
Power voltage:DCV:±30 ~±600V,
ACV:30 ~600V(50/60Hz)
Accuracy:± 2% rdg
4)Measure theflow: 0 to2.4mA
5)Measure thecapacitor
Supposemeasurements:5nF~50uF
Accuracy:± 5%rdg
Power:12Vbattery
Size:330 (L)×410 (W)×180 (D)mm
Accessories:
+7170(Maincord),
+7224A(Earthcord),
+7225A(Guardcord),
+7226A(lineprobe),
+7227A(Lineprobewithalligatorclips),
+8029(Extensionprod)
+8212-USB-W
