TABLE DIMENSIONS
Front Face : 8.0 in. (20.3 cm)
Top Face : 8.0 in. (20.3 cm)
TEST CAPABILITIES
Max. Acceleration: 10,000g
Min. Pulse Duration : 0.2 msec (half sine)
Max. Velocity Change : 75 – 150 ft./sec (22.9 – 45.7 m/sec)
Pulse Waveforms : Half Sine; Terminal Peak Sawtooth +Trapezoidal (with Optional Programmers )
MAXIMUM PAYLOAD : 250 lbs. (113 kg)
DIMENSIONS
Height : 115 – 175 in. (292 – 445 cm)
Side to Side : 36 in. (91.4 cm)
Front to Back : 53.7 in. (136.4 cm)
POWER REQUIREMENTS
Machine (hoists) : 200 – 240 VAC/3Φ/50 – 60 Hz: 10 amp min.; 380 – 480 VAC/3Φ/50 – 60 Hz: 5 amp min.
Machine (winch) : 100 – 120 VAC/1Φ/50 – 60 Hz: 30 amp min.
Controller: 100 – 120 VAC/1Φ/50 – 60 Hz: 1 amp min.; 200 – 240 VAC/1Φ/50 – 60 Hz: 1 amp min.
PNEUMATIC REQUIREMENTS
Plant Air: 90 psi (6.2 bar)
