Lisun SUG335 Transient High Voltage Impulse Generator
Manufacturer: Lisun Model: SUG335 - Contact
Call for the best price
Hanoi city: (024) 35.381.269
Danang city: (023) 63.747.711
Bac Ninh city: (0222)730.39.68
HCM city: (028) 38.119.636
Time of surge wave front: 1.2µs ± 30%
Time of half value of wave tail: 50µs ± 20%
Surge voltage: 1 ~ 12.5kV ≤ ±3%
Output Impendence: 42Ω
Polarity interval (Adjustable): 1 ~ 99s (The IEC60335:2010+A1:2013 page 43 clause 14 request)
Surge times (Adjustable): 1 ~ 9999 times
Polarity: positive and negative
How to check the Waveform: Built-in surge voltage probe (1000:1), connect with LISUN OSP1102 Oscilloscope directly
