Circuit: LSI microprocessor circuit
Display: LCD, size 52mm x 38mm
Measurement Functions:
mT (milli Tesla)
G (Gauss)
DC Measurement Range:
300.00 mT x 0.01mT
3,000.0 mT x 0.1 mT
3,000.0 G x 0.1G
30,000 G x 1G
AC Measurement Range:
150.00 mT x 0.01mT
1,500.0 mT x 0.1 mT
1,500.0 G x 0.1G
15,000 G x 1G
Sensor: Hall sensor
Frequency Response: AC measurement: 50 Hz / 60Hz
Temperature Compensation: Uses a temperature probe for automatic temperature compensation
Measurement Direction: Single axis
Data Logging Time:
Automatic: 1 second ~ 8 hours 59 minutes 59 seconds
Manual: Press the button to save
Supported Memory Card: 1GB ~ 16GB
Hold Function: Hold the value
Storage Function: (Max & Min values)
Sampling Time: Approximately 1 second
Data Output: Communication with computer via RS232 and USB interfaces
Operating Temperature: 0 ~ 50 °C
Operating Humidity: Less than 85 %RH
Power Supply: 1.5V DC x 6 batteries or 9V DC adapter (optional)
Weight: 385g
Dimensions:
Meter: 177 x 68 x 45 mm
Probe: 198 x 25 x 19 mm
