Capacity: 700VA
Operating mode: SPWM (Sinusoidal Pulse Width Modulation)
Input
Phase: 1φ2W
Voltage: 220V ± 10%
Frequency: 45-250Hz (0.01step)
Output
Phase: 1Φ2W
Voltage: 0 ~ 150VAC / 0 ~ 300VAC AUTO
Frequency: 45 ~ 250Hz (0.01step)
Maximum current:
L = 120V: 6A
H = 240V: 3A
Load regulation: 1%
Waveform distortion: 2% (low-end 120V, high-end 240V, with pure resistance load)
Frequency stability: 0.01%
Display: Voltage / current / Frequency / power / power factor
Voltage resolution: 0.01V
Frequency resolution: 0.01Hz
Current resolution: 0.001A
Storage: M1 ~ M5 (V_F_A)
Test accuracy:
Voltage: ± 0.5% FS + 5dgt
Electric current: ± 0.5% FS + 5dgt
Frequency: ± 0.01% FS + 5dgt
Power: ± 0.5% FS + 5dgt
Setting accuracy:
Voltage: ± 1% FS
Frequency: ± 0.1% FS
Current limit setting: 0 ~ Max Current (The maximum current is: maximum capacity / 240V or P / 240)
Output protection: Overcurrent, overtemperature, overload, short circuit
Operating environment: 0 ~ 40 ° C ≤80% RH
Bare metal size (mm): 365 * 150 * 430
Net weight (kg): 15
