MATRIX MDM-8155A Benchtop Digital Multimeter (5½ Digits)

Display digits: 220000(5½)

Maximum measurement speed: 7 times / sec

DC voltage: 10uV~1000V ±(0.015%+3)

DC current: 10nA~10A ±(0.05%+10)

AC voltage: 10uV~750V ±(0.2%+100)

AC current: 10nA~10A ±(0.3%+400)

Resistance: 10mΩ~200MΩ ±(0.02%+6)

Capacitance: 1pF~10mF ±(2%+5)

Frequence: 1Hz~20MHz ±(0.1%+10)

Period: 50ns~500ms ±(0.1%+3)

Mathematical functions: MX+B/MAX/MIN/dB/dBm/Rel/Comp Hi/Comp Low/Hold/Statistics

Resistance measurement: Support 2-wire, 4-wire in two ways.

Continuity test: When the resistance is less than 30 ohms, the buzzer sounds.

Diode test: Measurable range: 0～2V

AC+DC measurement: Support.

Trigger mode: Standard: automatic trigger, single trigger; Optional: external trigger.

Duty cycle measurement: 5.0%～95.0%. (the error is within 10 words.)

Square wave output: Frequence: 1Hz～100kHz, amplitude: 3V.(Optional.)

Limit test: Support.

Calibration: Support.

Temperature: Thermocouple: K/N/R/S/T/B/E/J/WRe325/WRe526; RTD: PT100/PT50/Cu100/ Cu50.

Communication Interface: Standard: USB Device; Optional: USB Host, RS232, GPIB, LAN, WIFI, Bluetooth.

Additional functions: Data hold, data record, data readback.
